76x105 PROFILE
Timber | Pine (other types of wood on demand) | ||
Frame size | 105x57mm (thickness x width) | ||
Standard color | White RAL9010 or NCS S0502Y | ||
Glass unit | 3-glass, thickness 36mm | ||
Spacer in glass unit | Aluminium or insulated | ||
Glass sealing | Sealing rubber | ||
Glazing beads from outside | PVC, white RAL9010 | ||
Aluminium water protection | White RAL9010 | ||
U-value | 0,9 W/m2K |
92x115 PROFILE
Timber | Pine (other types of wood on demand) | ||
Frame size | 115x57mm (thickness x width) | ||
Standard color | White RAL9010 or NCS S0502Y | ||
Glass unit | 3-glass, thickness 52mm | ||
Spacer in glass unit | Aluminium or insulated | ||
Glass sealing | Sealing rubber | ||
Glazing beads from outside | PVC, white RAL9010 | ||
Aluminium water protection | White RAL9010 | ||
U-value | 0,7 W/m2K |
76x105 PROFILE
Timber | Pine (other types of wood on demand) | ||
Frame size | 105x57mm (thickness x width) | ||
Standard color | White RAL9010 or NCS S0502Y | ||
Standard color for aluminium profiles | White RAL9010 or NCS S0502Y | ||
Glass unit | 3-glass, thickness 36mm | ||
Spacer in glass unit | Aluminium or insulated | ||
Glass sealing | Sealing rubber | ||
U-value | 0,9 W/m2K |
92x115 PROFILE
Timber | Pine (other types of wood on demand) | ||
Frame size | 115x57mm (thickness x width) | ||
Standard color | White RAL9010 or NCS S0502Y | ||
Standard color for aluminium profiles | White RAL9010 or NCS S0502Y | ||
Glass unit | 3-glass, thickness 54mm | ||
Spacer in glass unit | Aluminium or insulated | ||
Glass sealing | Sealing rubber | ||
U-value | 0,7 W/m2K |
Wood is a natural product and its tone, texture and fiber are different. When choosing a lacquered finish, these properties of wood will be visible.
The tone on the finished product will be different from the tone on your device screen. To make sure you choose a shade, contact us and we will arrange a sample review.
Varnish options for oak
Lacquered
Q 147 Z
Q 006 Z
Q 073 Z
Q 043 Z
Q 007 Z
Q 045 Z
Q 945 Z
Q 315 Z
Q 175 Z
Varnish options for pine
J-482-T
J-1705-T
J-1816-T
J-45-T
EICHE-EICHE
J-1519-T
J-1634-T
J-50-T
J-1636-T
G.7.10.79T
J-357-T
J-77-T
J-34-T
J-451-T
J-3165-T
J-65-T
J-775-T
J-427-T
J-297-T
J-482-T
Wood is a natural product and its tone, texture and fiber are different. When choosing a painted finish, the properties of this wood will remain under the paint layer and will not be visible.
The tone on the finished product will be different from the tone on your device screen. Below are the most commonly used color tones. Choose a color shade from the RAL or NCS color catalog.
RAL tones
RAL 3003
RAL 6007
RAL 7005
RAL 7008
RAL 7016
RAL 8008
RAL 8016
RAL 9005
RAL 9010
RAL 9016
When choosing wooden windows or doors with aluminum cladding on the outside, you can choose the shades of aluminum cladding from the RAL or NCS catalogs.
The following are the most commonly used shades for aluminum cladding. Contact us to clarify the availability of your chosen color shade.
RAL tones
RAL 3003
RAL 6007
RAL 7005
RAL 7008
RAL 7016
RAL 8008
RAL 8016
RAL 9005
RAL 9010
RAL 9016
